If your pool stays open through the winter, the pump is your freeze protection. Moving water doesn't freeze in the lines. Before the first hard freeze:
Don't turn the pump off to "protect" it. It's the most expensive mistake we see.
Check your freeze settings. Find out what air temperature your automation panel or timer is set to kick on at, and which circuits it protects.
Make sure the freeze speed actually moves water through every return, water feature, and the heater.
No automation or freeze timer? Run the pump 24/7 whenever it's below freezing. With a variable speed pump, 24/7 is the easier call anyway.
Have a power outage plan. If the power goes out in a hard freeze with no end in sight, shut off the breakers and drain the equipment.
Water expands when it freezes, and the plastic housings, unions, and fittings on your equipment pad aren't built to give. In most of the Southeast, a normal cold night isn't much of a threat as long as the water keeps moving. The trouble starts when the cold sticks around.
A few winters back, the Upstate of South Carolina went the better part of a week without getting above freezing. That's rare here, and the rarity is exactly what makes it dangerous: most owners have never had to deal with it. Across the pools our family's service business looks after, the vast majority came through fine. A small number still had damage, even with the pumps running the way they should. The usual first casualties:
The inline sacrificial anode housing, on systems that have one
Pump seal plates, which show up as a leak between the motor and the wet end
Pump housings and unions
Filters cracked less often, and usually after something else had already given. The good news is that nearly all of it was repairable. It was still an annoying, avoidable expense.
Then there was the owner who shut his equipment off because he thought that was the safe move. He ended up replacing his pump, his filter, his salt system, and a lot of plumbing. He didn't know any better. Now you do.
Most automated pools have a control panel (Pentair, Jandy, Hayward, and others) with freeze protection built in. The panel reads an outdoor air temperature sensor. When the air drops to a set point, it overrides your normal schedule and runs the pump until the temperature climbs back above that point.
That set point varies by panel and by installer. It's usually a few degrees above freezing, but don't take our word for it. Look up what yours is actually set to in your panel's settings, its app, or the manual.
While you're in there, check:
Which circuits are assigned to freeze protection. The pool circuit at minimum. If you have a spa, a booster pump, or a water feature, see whether those are included.
What speed the pump runs in freeze mode. More on that below.
Where the air sensor is. A sensor in direct afternoon sun or near a dryer vent can read warmer than the air around your equipment.
Many variable speed pumps also have their own freeze or thermal protection mode built into the drive. Your pump's manual will tell you how it's set and how it works alongside your automation.
If you have a plain timer with no freeze protection, you have two options whenever the temperature is below freezing:
Run the pump 24/7.
Turn the pump on by hand every time the air drops below freezing, and leave it on until it's back above.
Option two only works if you never miss a night. With a variable speed pump, running 24/7 at a reasonable speed is usually the better choice. Our variable speed pump energy guide breaks down what low-speed runtime actually costs.
A plain timer can also be upgraded with a freeze protection timer with a thermostat, a two-timer freeze protection control center, or an add-on air temperature sensor for a mechanical timer.
We've covered it, but it's worth repeating because it's the most common and the most expensive. A pump that's off is a pump full of still water, and so are the filter, heater, and pipes around it.
A variable speed pump on its lowest setting can hum along without pushing enough water through every line. Stand at the pool while freeze mode is running and look. Is water visibly moving at every return? Is the heater getting flow? If something looks dead, raise the freeze speed.
Waterfalls, deck jets, sheer descents, and similar features have their own plumbing. You have two choices: winterize them ahead of time, or run them the entire time freeze protection is on. Running them has a catch. Water that splashes onto the deck can freeze into a sheet of ice, and we've seen deck jets do exactly that. If you run them, keep people off the deck around them.
Freeze protection only works if the pump can pull water. Keep the water at the middle of the skimmer opening, and empty the skimmer and pump baskets before a cold snap. A pump that loses prime stops moving water, and nobody's out there watching it at 3 a.m.
This one catches a lot of first-time owners.
If your pool and spa share a pump and freeze protection covers both, the panel switches the valves back and forth between pool and spa so water moves through both sets of plumbing. On many Pentair systems the switch happens about every 15 minutes, and the pump pauses briefly while the valves turn.
Those valves turn slowly. Because the spa sits higher than the pool, a little spa water drains into the pool each time they cycle. On a normal day you'd never notice. But when freeze protection runs all night and into the next day, it adds up, and you can wake up to a spa that's half empty or close to drained.
It looks like a leak or a crack. It almost never is. It's just spa water draining into the pool.
To fix it, refill the spa by running the spillway, which pumps pool water back up into the spa. In freeze mode, the panel may not let you. You'll need to either turn the valves by hand or take the system out of freeze mode while the spa refills. If you take it out of freeze mode, remember to turn it back on.
Most of the time this is a minor annoyance. It turns into a bigger deal when freeze protection has to run for a couple of days straight, so check the spa level each morning during a long cold stretch.
No. Plenty of owners never turn the heater on all winter, and freeze protection does its job just fine.
In a long, hard freeze, running the heater on a low setting doesn't hurt anything. Pushing slightly warmer water through the system adds a little margin. The only downside is the cost. You don't need to heat the pool to swimming temperature.
Most salt cells stop producing chlorine once the water gets cold. Check your system's manual for its low-temperature cutoff. You can leave the cell in place, or swap in a blank (dummy) cell to protect it from freeze risk and wear while it isn't doing anything.
Either way, your pool still needs chlorine.
Southern winters swing. One week it's freezing, and the next it's in the 60s or 70s. Algae growth slows way down in cold water, roughly below 60°F, but algae doesn't die off, and a warm stretch can wake it right back up. A salt pool with zero chlorine and a couple of warm weeks can turn green in the middle of winter.
Our standing advice for salt pools that stay open all year: keep a small chlorine level going with tabs in a floater or feeder, or with liquid chlorine, and keep pH and alkalinity in range. Tablets add stabilizer (CYA) over time, so check that number now and then too.
The good news about winter is that your water is much easier to keep stable.
Less is burning through your chlorine. No hot sun, no swimmers, and far less organic debris once the leaves, pollen, and grass go dormant. Your chlorine lasts a lot longer.
Your filter stays cleaner. You won't need to clean the cartridge or backwash nearly as often. Watch the pressure gauge and clean the filter when the pressure climbs.
Algae is mostly asleep in cold water, until a warm spell.
Here's what we strongly don't recommend: closing the gate in November and not testing again until spring. It's the biggest winter mistake we see. You don't need to test as often as you do in summer, but every couple of weeks is plenty for most open pools. Keep chlorine, pH, and alkalinity where they belong. Your pool is a big investment, so protect it.
New to all this? Our beginner pool maintenance checklist covers the basics.
Freeze protection needs electricity. When the power goes out, the plan depends on how long it's out and how cold it gets.
Short outage, mild cold. Say the power is out for a couple of hours, it's in the mid-30s, and the high is 50. You're probably fine. Keep an eye on things, but there's no need to panic.
Long outage, hard cold, no end in sight. Now you're draining the equipment, which is basically an emergency winterization:
Turn the pool equipment breakers off first. If the power comes back while everything is drained, the pump can kick on and run dry.
Pull every drain plug on the equipment pad. Pump, filter, heater, booster pump, and anything else in line. Most have one or two near the bottom. If you can't find one, search your equipment's model number for the manual.
Open the filter's air relief valve so the tank drains fully, and loosen the pump lid to let air in.
Put the drain plugs in the pump basket so they don't get lost in the grass.
Get the water out of anything exposed. The more water you get out of the pump, filter, heater, and above-ground plumbing, the better your chances.
If your home has a standby generator, ask your electrician whether the pool pump can run on it.
Blankets help a little, not a lot. Draping blankets or towels over exposed plumbing can buy some time during a short outage. They don't replace draining. Keep them off the pump motor, and take them off before the power and the pump come back on.
When the power comes back: put the drain plugs back in, close the air relief valve, fill the pump basket with water to prime it, and then turn the breakers back on. Check for leaks and make sure water is moving at the returns before you walk away. If something cracked, call a local pool pro.
A properly closed pool, with the lines blown out and plugged and the equipment drained, is already protected. Before a hard freeze, do a quick check:
The equipment is still drained. Drain plugs out and stored in the pump basket, filter and heater empty. Make sure nobody "helpfully" put the plugs back in.
The water level is where you left it. If you lowered the water below the skimmer, heavy rain can bring it back up. Pump it down if needed.
The cover is secure. Pump standing water off a solid cover, and check the straps, anchors, or water bags.
Above ground pools: make sure the air pillow is still inflated and centered.
In places with long, hard winters, closing is the norm. Farther south, most owners keep the pump running with freeze protection. Either approach works when it's done right. What doesn't work is a pool that's half closed, with the pump off and the lines still full of water.
Getting ready to close? Shop our Winterizing Kits & Parts.
No. If your pool is open, the pump is your freeze protection. Turning it off leaves still water in the pump, filter, and pipes, and that's how equipment cracks. The one exception is a long power outage in hard cold, when you shut off the breakers and drain everything.
It depends on your system. Most panels are set a few degrees above freezing, but the exact number varies by brand and installer. Check your panel's settings or manual.
The entire time the air is below your freeze set point. Automation handles that for you. Without automation, run the pump 24/7 whenever it's below freezing.
On pool and spa combos, freeze protection cycles the valves between the pool and the spa. Each switch lets a little spa water drain into the lower pool, and over a long cold night it adds up. Refill the spa by running the spillway, turning the valves by hand if freeze mode won't let you.
No, it's optional. During a long, hard freeze, low heat adds a little margin if you don't mind the cost.
Cover the exposed plumbing if you want some short-term help during an outage. Don't cover the motor, and don't count on blankets in place of draining the equipment.
It will probably stop producing on its own once the water is cold. You can leave it in or swap in a dummy cell. Either way, keep chlorine in the pool with tablets or liquid chlorine.
