ChlorKing® CHLOR 10SM Salt Chlorinator

High-Volume Salt Chlorination for Commercial Pools

The ChlorKing® CHLOR 10SM is a heavy-duty, high-output salt chlorinator built for large-scale commercial pools and aquatic facilities. With patented single-cell technology and a self-cleaning 15,000-hour electrode, this system converts a mild saline solution (3,500–5,000 ppm) into pure chlorine — delivering a powerful 11 lbs/day output.

It’s plumbed in a simple 1” bypass configuration and powered by a durable, water-cooled industrial-grade switch-mode supply. Designed to save money, simplify maintenance, and enhance safety, the CHLOR 10SM is a go-to choice for demanding pool environments.

Key Features

• 11 lbs/day Chlorine Output: Handles high-capacity commercial pool sanitation

• Single-Cell Technology: Compact, reliable, and service-friendly

• Self-Cleaning Function: Reverse polarity extends cell life and reduces maintenance

• Bypass Installation: Uses standard 1” plumbing with just 20 GPM required

• Digital Toroidal Salt Sensor: Accurate, calibration-free salinity monitoring

• Water-Cooled Power Supply: Industrial-grade efficiency and durability

• Clear Cell Housing: Allows for visual inspection of chlorine production

• Proudly U.S. Made: Designed, manufactured, and supported in the USA

Technical Specifications

• Chlorine Output: 11 lbs / 24 hours

• Salt Requirement: 3,500 – 5,000 ppm

• Flow Rate: 20 GPM required (50 PSI max)

• Electrical:

  • Max Amps: 7.5 @ 240V or 15 @ 120V

  • Voltage: 120–240V, 50/60 Hz, single-phase

  • GFCI Breaker: 20 amp required

• Operating Temperature:

  • Air: 35°F to 115°F (2°C to 46°C)

  • Water: 59°F to 104°F (15°C to 40°C)

• Certifications: NSF-50, UL-1081, CSA-C22.2

• Plumbing: 1” inlet/outlet (bypass install)

• Dimensions:

  • Power Supply: 16”W × 22”H

  • Cell Housing: 11”W × 27”H

• Cell Lifespan: 15,000 hours

Installation & Compatibility

Designed for quick wall-mount installation, the CHLOR 10SM connects to your existing circulation system via 1” bypass plumbing. Bonding lugs and grounding Ts included for full commercial safety compliance.
